Airports for X-Plane

Staverton - Gloucester

Airport details

CountryUnited Kingdom
StateEngland
RegionEG
AirspaceLondon Ctr
MunicipalityTewkesbury
Elevation101ft (31m)
TimezoneGMT +0
Coordinates51.89582, -2.16428
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeEGBJ
IATA codeGLO
FAA coden/a

Communication

Gloucester ATIS127.480
Gloucester Tower122.905
Gloucester RADAR120.980
Gloucester Gloucester Approach128.555
Gloucester Tower Departure122.905

Approach frequencies

ILS-cat-IRW27109.9518.00mi
3.5° GSRW27109.9518.00mi

Runway info

Runway 09 / 27
 length1429m (4688ft)
 bearing86° / 266°
 width37m (121ft)
 surfaceasphalt
 displ threshold30m (98ft) / 283m (928ft)
Runway 04 / 22
 length980m (3215ft)
 bearing48° / 228°
 width23m (75ft)
 surfaceasphalt
 displ threshold0m (0ft) / 87m (285ft)
Runway 04R / 22L
 length306m (1004ft)
 bearing48° / 228°
 width19m (62ft)
 surfacegrass

Airport layout - taxiway location G2


Taxiway locations

 A  A1  A2  A3  A4  A5  A6  B
 B1  B2  B3  C2  D1  D2  E1  E2
 G1  G2  H1  H2  J  K  L  M
 N1
Parking locations

 Air  Cotswold  GA  Heli  NE  RGV  South  Stand

Nearby beacons

codeidentifierdistbearingfrequency
GSTGLOUCESTERSHIRE NDB0.2223°331
FFAFAIRFORD TACAN18.7120°113.40
BZBRIZE NORTON NDB22.6105°386
BZNBRIZE NORTON TACAN22.6105°111.90
OFFILTON NDB27.5229°325
OXOXFORD NDB31.494°367
HONHONILEY VOR/DME33.247°113.65
SHSHOBDON NDB33.6296°426
BHXBIRMINGHAM NDB36.836°406
BRIBRISTOL NDB37.1227°414
WBAWOLVERHAMPTON NDB37.4351°356
WOLDME37.4351°108.60
CPTCOMPTON VOR/DME42.7113°114.35
BDNBOSCOMBE DOWN TACAN47.4151°108.20
VLNYEOVILTON TACAN56.3208°111
TNLTATENHILL NDB5723°327
SWBSHAWBURY VOR/DME57.1331°116.80
WPLWELSHPOOL NDB57.1307°323
YVLDME60.2207°109.05
YVLYEOVIL NDB60.3208°343
EMWEAST MIDLANDS NDB61.737°393
EASSOUTHAMPTON (EASTLEIGH) NDB64139°391
SAMSOUTHAMPTON VOR/DME64.2139°113.35
EMEEAST MIDLANDS NDB66.546°353

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09KUPET (86°)KUPET 3000ft
BJ09I (5mi, 86°) 2500ft
RW09SOSAB (72°)SOSAB 3000ft
BJ09I (5mi, 21°) 2500ft
RW09UVNOP (99°)UVNOP 3000ft
BJ09I (5mi, 141°) 2500ft
 RNAVBJ09I 2500ft
BJ09F (5mi, 86°) 1700ft
EGBJ (5mi, 85°) 124ft
(3119mi, 178°) 1500ft
(turn) 2800ft
GST (3118mi, 358°) 2800ft
RW27LAPKU (249°)LAPKU 2500ft
NIRMO (5mi, 170°) 2500ft
BJ27F (5mi, 266°) 2000ft
RW27NIRMO (267°)NIRMO 2500ft
BJ27F (5mi, 266°) 2000ft
RW27REKLO (283°)REKLO 2500ft
NIRMO (5mi, 350°) 2500ft
BJ27F (5mi, 266°) 2000ft
 RNAVBJ27F 2000ft
EGBJ (5mi, 267°) 127ft
(3119mi, 178°) 1500ft
GST (3118mi, 358°) 2800ft
