Airports for X-Plane

Bâle/mulhouse - Bale-mulhouse

Airport details

CountryFrance
StateGrand Est
RegionLF
AirspaceReims Ctr
MunicipalitySaint-Louis
Elevation879ft (268m)
TimezoneGMT +1
Coordinates47.60556, 7.52290
Magnetic var
Typeland
Available sinceX-Plane v10.32
ICAO codeLFSB
IATA codeBSL
FAA coden/a

Communication

Bale-Mulhouse LFSB ATIS127.880
Bale-Mulhouse BALE Ground Control121.605
Bale-Mulhouse BALE Tower118.300
Bale-Mulhouse BALE Approach119.355
Bale-Mulhouse BALE Approach130.900
Bale-Mulhouse BALE Approach124.105
Bale-Mulhouse BALE Approach118.580
Bale-Mulhouse BALE Departure119.355

Approach frequencies

ILS-cat-IIIRW15111.5518.00mi
ILS-cat-IRW33109.3518.00mi
3.5° GSRW33109.3518.00mi
3° GSRW15111.5518.00mi

Runway info

Runway 15 / 33
 length3904m (12808ft)
 bearing145° / 325°
 width60m (197ft)
 surfaceconcrete
 displ threshold0m (0ft) / 1120m (3675ft)
 blast zone105m (344ft) / 0m (0ft)
Runway 08 / 26
 length1714m (5623ft)
 bearing81° / 261°
 width60m (197ft)
 surfaceconcrete
 displ threshold0m (0ft) / 115m (377ft)

Airport layout - parking location Ramp


Taxiway locations

 A  B  C  C1  D  E  F  G
 H  J  K  L  P  V
Parking locations

 F1  F11  F12  F2  F21  F22  F3  F4
 F6  F7  F8  F82  F83  F9  F92  F93
 GA  Gate  Maintenance  Ramp

Nearby beacons

codeidentifierdistbearingfrequency
BSBASLE-MULHOUSE NDB1.6153°376
BLMBASLE-MULHOUSE VOR/DME1.8319°117.45
BNBASLE-MULHOUSE NDB3.8322°353
HOCDME10.1134°113.20
MBMONTBELIARD NDB25260°330
GREGRENCHEN VOR/DME25.7194°115.45
WILWILLISAU VOR/DME30138°116.90
HRHERICOURT NDB32.1267°289
HOCOLMAR-HOUSSEN NDB32.3343°380
TRADME37.385°114.30
LPSLES EPLATURES NDB43.1234°403
LHRLAHR NDB46.121°337
LRDDME47.122°108.05
FRIFRIBOURG VOR/DME51.2200°110.85
STRSTRASBOURG ENTZHEIM VOR/DME543°115.60
SESTRASBOURG NDB59.511°412

Departure and arrival routes

Transition altitude7000ft
SID end pointsdistanceoutbound heading
RW15
 ELBE7S11mi68°
 OLBE7S, OLBE7Y19mi161°
 LUME7S19mi242°
 MORO7T37mi256°
 TORP7T36mi262°
 LASA7S47mi303°
RW33
 ELBE7N11mi68°
 OLBE7N19mi161°
 LUME7N19mi242°
 MORO7N37mi256°
 TORP7N36mi262°
 LASA7N47mi303°

STAR starting pointsdistanceinbound heading
ALL
 ARPU8K34.994°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW15ADOGA (170°)ADOGA
IVDEV (12mi, 203°) 6000ft
RW15ALTIK (96°)ALTIK
1SB15 (9mi, 39°)
IVDEV (6mi, 73°) 6000ft
 RNAVIVDEV 4000ft
FSB15 (4mi, 145°) 4000ft
LFSB (11mi, 144°) 914ft
TSB15 (2mi, 153°) 4000ft
ALTIK (17mi, 280°) 5500ft
RW33ALTIK (96°)ALTIK
3SB33 (9mi, 93°)
2SB33 (14mi, 145°)
1SB33 (9mi, 145°)
IXUDI (5mi, 72°) 7400ft
 RNAVIXUDI 6200ft
FSB33 (4mi, 325°) 6200ft
LFSB (15mi, 326°) 930ft
TSB33 (6mi, 323°)
ALTIK (13mi, 261°) 7000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ARPU8KALTIKVHFright271 (91)°5500ft - 11000ftDME 5.0mi220
ARPU8KARPUSVHFleft271 (91)°10000ft - 14000ftDME 5.7mi220
LUME8KALTIKVHFright271 (91)°5500ft - 11000ftDME 5.0mi220
STR8KALTIKVHFright271 (91)°5500ft - 11000ftDME 5.0mi220
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
