Airports for X-Plane

Columbus - John Glenn Columbus Intl

Airport details

CountryUnited States of America
StateOhio
RegionK5
AirspaceIndianapolis Ctr
MunicipalityColumbus
Elevation813ft (248m)
TimezoneGMT -5
Coordinates39.99694, -82.89217
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKCMH
IATA codeCMH
FAA codeCMH

Communication

John Glenn Columbus Intl ATIS124.600
John Glenn Columbus Intl UNICOM122.950
John Glenn Columbus Intl Columbus Clearance126.300
John Glenn Columbus Intl Columbus Ground121.900
John Glenn Columbus Intl Columbus Tower132.700
John Glenn Columbus Intl Columbus Approach118.200
John Glenn Columbus Intl Columbus Departure125.950

Approach frequencies

ILS-cat-IIRW10R111.7518.00mi
ILS-cat-IIRW28L111.7518.00mi
ILS-cat-IRW10L109.118.00mi
ILS-cat-IRW28R109.118.00mi
3° GSRW10R111.7518.00mi
3° GSRW10L109.118.00mi
3° GSRW28L111.7518.00mi
3° GSRW28R109.118.00mi

Runway info

Runway 10R / 28L
 length3076m (10092ft)
 bearing93° / 273°
 width50m (164ft)
 surfaceconcrete
 blast zone61m (200ft) / 61m (200ft)
Runway 10L / 28R
 length2433m (7982ft)
 bearing93° / 273°
 width46m (150ft)
 surfaceasphalt
 blast zone61m (200ft) / 61m (200ft)

Airport layout


Taxiway locations

 B  B1  B2  B3  B4  B5  C  C1
 C2  C3  C4  C5  C6  C7  C8  C9
 D  D1  E  E1  E2  E3  E4  E5
 E6  F  F1  F2  F3  F4
Parking locations

 A4  A7  B20  B25  B29  B30  B32  C46
 C49  C50  C56  East  Lane  NetJets  SE  Signature

Nearby beacons

codeidentifierdistbearingfrequency
LCPICKL (COLUMBUS) NDB7.4154°376
LCKRICKENBACKER (COLUMBUS) TACAN11.4191°134.20
OSFULER (COLUMBUS) NDB14.8284°515
DDCOBBS (COLUMBUS) NDB16.3207°253
APEAPPLETON VORTAC16.763°116.70
BUBOUTN (COLUMBUS) NDB17.9240°230
XUBYELLOW BUD (CIRCLEVILLE) VOR28.5190°112.50
CSSCOURT HOUSE (WASHINGTON) NDB33.1232°414
BUDBUCKEYE (MARION) VOR38345°109.80
XSFSPRINGFIELD TACAN44.7260°133.80
SGHDME44.9260°113.20
ZZVZANESVILLE VOR/DME46.193°114.95
ILAIRBO (WILMINGTON) NDB49.4239°407
EOPWAVERLY NDB49.8183°385
MFMANNS (MANSFIELD) NDB50.530°372
MXQMIDWEST (WILMINGTON) VOR/DME54238°112.90
MFDMANSFIELD VORTAC54.119°108.80
UGSUNIVERSITY (ATHENS) NDB56.8134°250
HWCUBLA (WILMINGTON) NDB59.6237°299
FBCFLAG CITY VORTAC69.7318°108.20

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW10 (ALL)
 NCLUS224mi198°
RW28 (ALL)
 NCLUS224mi198°

STAR starting pointsdistanceinbound heading
RW10 (ALL)
 CBUSS225.4227°
RW10L
 JAKTZ124.555°
 DUBLN116.5131°
 CLPRR130.2295°
 SCRLT125.0302°
RW10R
 JAKTZ124.555°
 DUBLN116.5131°
 CLPRR130.2295°
 SCRLT125.0302°
RW28 (ALL)
 JAKTZ124.555°
 DUBLN116.5131°
RW28L
 CBUSS225.4227°
 CLPRR130.2295°
 SCRLT125.0302°
RW28R
 CBUSS225.4227°
 CLPRR130.2295°
 SCRLT125.0302°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW10LYFLANK (95°)FLANK 3300ft
 RNAVFLANK 3300ft
CCREW (3mi, 93°) 2300ft
SILKN (2mi, 93°) 1660ft
KCMH (3mi, 98°) 865ft
(5078mi, 116°) 1400ft
APE (5065mi, 296°) 3000ft
APE (turn)
RW10LZAMITE (94°)AMITE
POGLE (3mi, 93°) 4000ft
MESRE (2mi, 93°) 3300ft
CCREW (3mi, 93°) 2300ft
RW10LZMADZY (111°)MADZY 5000ft
JARTO (4mi, 158°) 3900ft
MESRE (2mi, 117°) 3300ft
CCREW (3mi, 93°) 2300ft
RW10LZSLATS (25°)SLATS 6000ft
ELTEE (4mi, 273°) 5100ft
CCREW (6mi, 5°) 2300ft
RW10LZWILGO (162°)WILGO 6000ft
HINDO (3mi, 273°) 4900ft
OMANY (3mi, 249°) 4000ft
FANAS (4mi, 163°) 2700ft
CCREW (1mi, 104°) 2300ft
RW10LZYUKAN (77°)YUKAN 5000ft
EVELE (4mi, 30°) 3900ft
MESRE (2mi, 70°) 3300ft
CCREW (3mi, 93°) 2300ft
 RNAVCCREW 2300ft
KCMH (5mi, 96°) 865ft
(5078mi, 116°) 1400ft
APE (5065mi, 296°) 3000ft
APE (turn)
RW10RYBATTI (92°)BATTI 3300ft
 RNAVBATTI 3300ft
SHUUU (3mi, 93°) 2300ft
DEBBY (2mi, 93°) 1660ft
KCMH (3mi, 90°) 859ft
(5078mi, 116°) 1400ft
BU (5092mi, 296°) 3000ft
BU (turn)
RW10RZEPATY (92°)EPATY
AVUSE (3mi, 93°) 4000ft
JOGMA (2mi, 93°) 3300ft
SHUUU (3mi, 93°) 2300ft
RW10RZHALUR (29°)HALUR 6000ft
TOYON (3mi, 273°) 4900ft
SHUUU (5mi, 5°) 2300ft
RW10RZHANTI (76°)HANTI 5000ft
ZOGIK (4mi, 30°) 3900ft
JOGMA (2mi, 69°) 3300ft
SHUUU (3mi, 93°) 2300ft
RW10RZHELDI (109°)HELDI 5000ft
RRNLD (4mi, 159°) 3900ft
JOGMA (2mi, 117°) 3300ft
SHUUU (3mi, 93°) 2300ft
RW10RZWILGO (162°)WILGO 6000ft
CASER (3mi, 273°) 5100ft
HESAR (3mi, 244°) 4000ft
ARNIT (4mi, 154°) 2700ft
SHUUU (1mi, 103°) 2300ft
 RNAVSHUUU 2300ft
KCMH (5mi, 91°) 859ft
(5078mi, 116°) 1400ft
BU (5092mi, 296°) 3000ft
BU (turn)
RW28LYBAZEL (275°)BAZEL 3300ft
 RNAVBAZEL 3300ft
LMITD (3mi, 273°) 2300ft
ZIGTI (2mi, 273°) 1560ft
KCMH (3mi, 277°) 867ft
(5078mi, 116°) 1400ft
BU (5092mi, 296°) 3000ft
BU (turn)
RW28LZHAMON (274°)HAMON
VUZLI (3mi, 273°) 4000ft
BKEYE (2mi, 273°) 3300ft
LMITD (3mi, 273°) 2300ft
RW28LZJESCE (340°)JESCE 6000ft
WILSO (3mi, 93°) 4800ft
NOLNE (4mi, 53°) 3500ft
LMITD (3mi, 308°) 2300ft
RW28LZNHERD (259°)NHERD 5000ft
JEUDY (4mi, 213°) 3900ft
BKEYE (2mi, 250°) 3300ft
LMITD (3mi, 273°) 2300ft
RW28LZTEEZE (206°)TEEZE 6000ft
TAYZZ (4mi, 93°) 5100ft
LMITD (6mi, 185°) 2300ft
RW28LZXAVYR (290°)XAVYR 5000ft
GUBER (4mi, 338°) 3900ft
BKEYE (2mi, 298°) 3300ft
LMITD (3mi, 273°) 2300ft
 RNAVLMITD 2300ft
KCMH (5mi, 275°) 867ft
(5078mi, 116°) 1400ft
BU (5092mi, 296°) 3000ft
BU (turn)
RW28RYBAATZ (272°)BAATZ 3300ft
 RNAVBAATZ 3300ft
WEEKZ (3mi, 273°) 2300ft
UNOIT (3mi, 273°) 1480ft
KCMH (3mi, 268°) 862ft
(5078mi, 116°) 1400ft
APE (5065mi, 296°) 3000ft
APE (turn)
RW28RZFAVUS (256°)FAVUS 5000ft
BOLDS (4mi, 213°) 3900ft
WINAT (2mi, 250°) 3300ft
WEEKZ (3mi, 273°) 2300ft
RW28RZJESCE (340°)JESCE 6000ft
HUSOR (3mi, 93°) 5100ft
GIMPS (5mi, 49°) 3500ft
WEEKZ (4mi, 304°) 2300ft
RW28RZTEEZE (206°)TEEZE 6000ft
DWYFE (3mi, 93°) 4900ft
WEEKZ (5mi, 185°) 2300ft
RW28RZWERUP (289°)WERUP 5000ft
SINPE (4mi, 338°) 3900ft
WINAT (2mi, 298°) 3300ft
WEEKZ (3mi, 273°) 2300ft
RW28RZYELYU (272°)YELYU
ORDIW (3mi, 273°) 4000ft
WINAT (2mi, 273°) 3300ft
WEEKZ (3mi, 273°) 2300ft
 RNAVWEEKZ 2300ft
KCMH (5mi, 270°) 862ft
(5078mi, 116°) 1400ft
APE (5065mi, 296°) 3000ft
APE (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
DUBLN1IKALEVHFright261 (81)°DME 15.0miICAO rules
DUBLN1JADUBVHFright260 (80)°DME 15.0miICAO rules
JAKTZ1JAKTZVHFleft251 (71)°DME 15.0miICAO rules
JAKTZ1JIMURVHFleft241 (61)°DME 15.0miICAO rules
*) magnetic outbound (inbound) holding course
