Country | Ireland |
State | County Dublin |
Region | EI |
Airspace | Shannon Ctr |
Municipality | South Dublin |
Elevation | 316ft (96m) |
Timezone | GMT +0 |
Coordinates | 53.30601, -6.44111 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | EIME |
IATA code | n/a |
FAA code | n/a |
Casement AB Baldonnel Information | 122.805 |
Casement AB Baldonnel Ground | 121.755 |
Casement AB Baldonnel Tower | 123.500 |
Casement AB Baldonnel Approach | 122.000 |
ILS-cat-I | RW10 | 109.35 | 18.00mi |
3° GS | RW10 | 109.35 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
BAL | BALDONNEL VOR/DME | 0.4 | 227° | 115.80 |
OE | DUBLIN NDB | 7.4 | 6° | 316 |
DAP | COLLINSTOWN VOR/DME | 8.6 | 50° | 111.20 |
KLY | KILLINEY NDB | 12.2 | 96° | 378 |
DUB | DUBLIN VOR/DME | 12.5 | 35° | 114.90 |
OP | DUBLIN NDB | 12.6 | 70° | 397 |
GMN | DME | 21.7 | 31° | 112.90 |
GMN | GORMANSTON NDB | 21.9 | 32° | 334 |
GTG | DME | 29.2 | 147° | 114.15 |
MCM | DME | 39.8 | 323° | 114.40 |
Transition altitude | 5000ft |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW22 | |||
OLAP1K | 41.7 | 119° | |
BAML1K | 50.7 | 166° | |
NIMA1K | 46.7 | 227° | |
BOYN1K | 43.5 | 244° | |
BAGS1K | 40.4 | 248° | |
RW28 | |||
BUNE1S | 41.5 | 15° | |
SUTE1S | 33.8 | 45° | |
OSGA1S | 33.5 | 73° | |
LIPG1S | 36.8 | 284° | |
VATR1S | 56.5 | 309° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BAGS1K | KERAV | VHF | right | 28 (208)° | 5000ft - 14000ft | 1.0min timed | 230 |
BAML1K | KERAV | VHF | right | 28 (208)° | 5000ft - 14000ft | 1.0min timed | 230 |
BOYN1K | KERAV | VHF | right | 28 (208)° | 5000ft - 14000ft | 1.0min timed | 230 |
BUNE1S | SORIN | VHF | left | 165 (345)° | 5000ft - 14000ft | 1.0min timed | 230 |
LIPG1S | SORIN | VHF | left | 165 (345)° | 5000ft - 14000ft | 1.0min timed | 230 |
NIMA1K | KERAV | VHF | right | 28 (208)° | 5000ft - 14000ft | 1.0min timed | 230 |
OLAP1K | KERAV | VHF | right | 28 (208)° | 5000ft - 14000ft | 1.0min timed | 230 |
OSGA1S | SORIN | VHF | left | 165 (345)° | 5000ft - 14000ft | 1.0min timed | 230 |
SUTE1S | SORIN | VHF | left | 165 (345)° | 5000ft - 14000ft | 1.0min timed | 230 |
VATR1S | SORIN | VHF | left | 165 (345)° | 5000ft - 14000ft | 1.0min timed | 230 |
*) magnetic outbound (inbound) holding course |
