Heringsdorf
Airport details
| Country | Germany |
| State | Mecklenburg-Vorpommern |
| Region | ED |
| Airspace | Bremen Ctr |
| Municipality | Zirchow |
| Elevation | 90ft (27m) |
| Timezone | GMT +1 |
| Coordinates | 53.87978, 14.13728 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | EDAH |
| IATA code | HDF |
| FAA code | n/a |
Communication
| Heringsdorf Heringsdorf Tower | 132.830 |
| Heringsdorf Langen Radar | 132.650 |
Approach frequencies
| ILS-cat-I | RW28 | 111.3 | 18.00mi |
| 3° GS | RW28 | 111.3 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| HC | HERINGSDORF NDB | 1.6 | 97° | 330 |
| FLD | FRIEDLAND VOR/DME | 21.5 | 258° | 117.15 |
| SCZ | SZCZECIN VOR/DME | 31.4 | 111° | 114.75 |
Departure and arrival routes
| Transition altitude | 5000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW10 | |||
| MASO1A | 18mi | 275° | |
| PENE2A | 20mi | 298° | |
| RW28 | |||
| MASO1B | 18mi | 275° | |
| PENE2B | 20mi | 298° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| UDAX1H | 16.8 | 75° | |
| PENE2H | 19.5 | 118° | |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| PENE2H | HC | FIX | right | 246 (66)° | > 3000ft | 1.0min timed | ICAO rules |
| UDAX1H | HC | FIX | right | 246 (66)° | > 3000ft | 1.0min timed | ICAO rules |
| *) magnetic outbound (inbound) holding course | |||||||
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
